Modern Sliding Door

The Marvin Modern Sliding door showcases industry-leading innovation, authentic modern design, and precision engineering with the strength and thermal performance of High-Density Fiberglass.

Material
High-Density Fiberglass Exterior | Extruded Aluminum Interior
Tree icon
Interior Color
5 Color Options
Exterior Color
5 Color Options

Modern Sliding Door

Details and Features
Details and Features

Sizing

Available in widths up to 5' and heights up to 12'

Material

High-Density Fiberglass Exterior | Extruded Aluminum Interior

Standard Performance Ratings

Up to PG40 for air, water, and structural integrity


Catalog + Technical Documents

Get Modern product resources here, including manuals, specifications, warranty information, and catalog.

Modern Product Catalog
Marvin Limited Warranty
View All Tech Specs

High-Density Fiberglass Exterior

Marvin Modern products feature High-Density Fiberglass for superior durability and energy efficiency.

Excellent thermal insulator

Resists cracks over time

Withstands extreme conditions

Low-maintenance finish


Security Options


Lock Status Sensor

Lock Status Sensor works with popular security systems, and can work in tandem with Marvin Connected Home™ smart window and door solutions.
Read more



Specialty Features


Exceptional Material Strength

The strength of High-Density Fiberglass allows for larger glass, narrow profiles, and less expansion and contraction over time.

Premium Finish

All Modern windows and doors have durable thermoset finishes that resist scratching, marring, and fading.

Thermal Performance

Low thermal conductivity rate of High-Density Fiberglass, combined with energy-efficient glass, including dual- and triple-pane glass options on windows and doors.

Design Options
Design Options
Color & Finish

The Modern collection features an intentionally curated, low-gloss interior color palette that evokes the elemental nature of modern design. Choose from a range of rich, neutral color options. Select split interior and exterior colors or matching colors designed to coordinate.

Exterior Colors


Interior Colors

Glass

Our specialty glass options include glass for unique project needs like sound abatement (STC/OITC) and high altitudes.

A variety of decorative glass options, including those shown below and others, are available to meet the unique needs of each project. Tempered or laminated glazing is available in Frosted, Obscure, Gray, or Bronze Tint.

Hardware

Hardware Styles

Featuring a unique and minimalist design with square corners and vertical slide locks, Modern door hardware minimizes visual distraction and maintains sleek sightlines. All fasteners are stainless steel, and a multi-point lock engages when the door is closed for a secure lock and tight seal from top to bottom. Choose from keyed or non-keyed locking and finger pulls for units that are pocketed into the wall for access to panels when the door is open.

A Marvin exclusive, our commercial-grade hardware is some of the toughest in the industry.

Door Hardware Finishes

Hardware finish samples are approximate. Please visit your local Marvin dealer to see hardware finish samples.

Screens

Available with a convenient sliding screen made from Marvin Bright View™ mesh — a fiberglass screen mesh that provides improved airflow and more natural light while keeping insects out. Bright View repels water and resists dirt and grime for a sharp, clear view.

Divided Lites

Divided Lites

Achieve a unique aesthetic with divided lites on any Modern window or door. Select from a variety of customizable patterns, available on both dual pane and triple pane products.

Paired with aluminum SDL bars on the exterior of the glass, an aluminum spacer bar is installed between the glass. Available in ⅞" and 1-⅛" widths and five colors.

The 2-⅞" Simulated Frame, also with black spacer bars, features an aluminum interior and High-Density Fiberglass exterior. It can be combined with ⅞" or 1-⅛" SDL bars in Simulated Rail Rectangular, Simulated Rail Prairie 6, Simulated Rail Prairie 9, and Simulated Frame patterns.

Patterns

Simulated divided lites are available in a selection of pre-designed patterns.

Sills

The fiberglass-reinforced Ultrex® sill runs in a single, continuous piece up to 20' no matter what door size or configuration you select. This uninterrupted sill eases installation by removing the need to splice the sill on the job site. It also eliminates the potential for water to seep through any seams. A water management and weep system is integrated into the performance sill. This integrated system allows water to efficiently exit through weep holes to the exterior, keeping water directed to the outside of the home. The performance sill provides two tracks, for interior and exterior panels, and an integrated track for the top hung screen — all seamless to eliminate debris collection areas on the sill.

Design Files
Design Files

2D Elevations

2D Operating Details

3D

Installation Information
Installation Information

The Modern collection features a modular design and installation system that delivers consistent profiles and expansive glass.


Through Jamb

Available through jamb and installation bracket options


Screens

Sliding screen is available as a option for field installation


Corner Keys

Integral corner keys keeps window and door units square and corners sealed


Fully Custom Sizes

Custom sizes are available on windows and doors in ¹⁄₆₄ " increments for the perfect fit every time


Field Mulling

Sliding doors can be field mulled to other sliding doors to achieve larger expanses with consistent sightlines and 6-⁹⁄₁₆" jamb depths


Built-in Drywall Return Recess

A gap on the back side of the frame interior conceals drywall for a seamless appearance. Optional drywall return cover also available.


Shims Provided

Heavy duty composite shims are included with every window or door.


Job Boxes

Custom-assembled for the specific project to save time and remove hassle and guesswork on site. Consolidates installation components, including fasteners for pre-drilled holes. Also serves as a safe space for hardware until it’s time to add finishing touches.


In-Rough Opening Field Mulling

Certified up to ¾" on each side of the unit to allow for ribbon mulling on site.


Service & Replacement Parts
Service & Replacement Parts

Find information on Modern product service, care, and replacement parts.



Technical Resources

Modern Sliding Door Technical Specifications

Find technical documents for this product, including installation instructions, sizes and elevations, 3D drawings, architectural detail manuals, and more.

Get the Modern Catalog

Get detailed information on the Modern product line including types of windows and doors, color and finish options, sizing, hardware, and more.
